"D" type Air cooled CNG standard compressor station

SN

Model

Capacity
Nm3/h

Inlet pressure
MPa

Outlet pressure
MPa

Type/Stage

Lubricating

Cooling

Motor power
KW

Dimension
L*M*H  mm

Weight
Kg

Note

1

DF-0.4/(48-75)-250
CNG Compressor

1100～1800

4.8～7.5

25

D/2

Oil inject

Air Cooled

110

4000*2250*2400

5500

2

DF-0.5/(22-48)-250
CNG Compressor

650～1400

2.2～4.8

25

D/2

110

4000*2250*2400

5500

3

DF-0.8/(14-22)-250
CNG Compressor

700～1100

1.4～2.2

25

D/3

110

4000*2250*2400

5500

4

DF-1.2/(6-14)-250
CNG Compressor

500～1000

0.6～1.4

25

D/3

110

4000*2250*2400

5500

5

DF-1.6/(3.5-6)-250
CNG Compressor

430～670

0.35～0.6

25

D/4

110

4000*2250*2400

5500

6

DF-2.1/(1-3.5)-250
CNG Compressor

250～550

0.1～0.35

25

D/4

110

4000*2250*2400

5500

"M "type water cooled CNG Compressor station

SN

Model

capacity
Nm3/h

Inlet Pressue
MPa

Outlet pressure
MPa

Structure/stage

Lubricating

Cooling

Motor power
KW

Dimension
L*M*H mm

Weight
Kg

Note

1

D-0.8/(48-75)-250
CNG Compressor

2200～3600

4.8～7.5

25

D/2

Oil inject

Water cooled

220

4500*2600*1500

6500

2

D-1/(22-48)-250
CNG Compressor

1300～2800

2.2～4.8

25

D/2

220

4500*2600*1500

6500

3

D-1.6/(14-22)-250
CNG Compressor

1400～2200

1.4～2.2

25

D/3

220

4500*2600*1500

6500

4

D-2.4/(6-14)-250
CNG Compressor

1000～2000

0.6～1.4

25

D/3

220

4500*2600*1500

6500
