Oxygen gas (O2) Compressor

Model NO.: BRC-O2

Lubrication Style: Oil-free

Power Source: AC Power

Configuration: Portable

Type: Reciprocating

Model Number: Brc-O2

Place of Origin: China

Compressed Grade: 4

Mute: Yes

Working Principle: Oil-Free Lubrication Reciprocating Type Booster

Cooling Type: Wind or Water Cooling

Power Consumption: 1.5-45kw

Rpm Range: 400-800rpm

Capacity Range: 5, 10, 20, 30, 40, 50nm3/H

Outlet Pressure: 150bar

Export Markets: Global

Product Description

BROTIE High Pressure Oil-free Oxygen Compressor(150bar)

This series are designed for oxygen cylinder purpose only.

Model OW-30/4-150

Flow Capacity 30Nm3/h

Compressing Grade 4grades

Inlet Pressure 4bar

Outlet Pressure 150bar

Outlet Temperature 50C

Inlet Size DN40

Outlet Size Customized

Ambient Temperature Normal temperature

Cooling System Water cooling 2t/h

Lubrication No Lubrication

Rotating Speed 400rpm

Power Consumption 11Kw

Weight 940kg

Dimensions 1650*850*1650mm

All parts which contact with O2 gas are made of anti-rot material.

For more information, pleaes do not hesitate to contact.
